Private Pilot Airplane practice question 21

(Refer to FAA-CT-8080-2H, Figure 47.) While on final approach to a runway equipped with a standard 2-bar VASI, the lights appear as shown by illustration D. This means that the aircraft is

FAA-CT-8080-2H, Figure 47. VASI Illustrations. U.S. Government work (public domain). Source PDF. Tap to enlarge.

Show answer

Correct answer: B. below the glide path.

On a two-bar VASI, all red (illustration D) means the aircraft is below the glide path. Red over white is on the glide path; all white is above it.

References

AIM 2-1-2
